Type III

Water from reverse osmosis

This water quality is intended for less critical applications when pure water for general laboratory applications is required.

It is ideal for the supply of autoclaves, dishwashers and ultrapure water systems.

OmniaLabRO

The powerful for constantly large quantities of pure water.
For H2O pure type III.



If there is a need for constantly large quantities of reverse osmosis water in the laboratory, the OmniaLabRO is used. The system meets the international water standard type III.



In addition, the OmniaLabRO system holds 100 liters of reverse osmosis water in a storage tank ready for withdrawal. This system is used to supply autoclaves, laboratory dishwashers, humidifiers, and ultrapure water systems.

Brochure OmniaLabRO (PDF)
  • OptiFill Dispenser is standard
  • With 100 l pure water tank
  • Tank volume display in percent
  • Tank volume can be modularly increased
  • Leakage sensor is standard

OmniaLabRO 20OmniaLabRO 40OmniaLabRO 60
Reverse osmosis water type III
Pure water performance at 15 °C [l/h]204060
RO membrane retention rate for ions, germs and bacteria [%]> 98> 98> 98

OmniaLabRO 20OmniaLabRO 40OmniaLabRO 60
Softened or hardness-stabilized water according to DIN 2000
Feedwater pressure [bar]1 up to 61 up to 61 up to 6
Conductivity at 25 °C [µS/cm]< 2000*< 2000*< 2000*
Colloid index SDI< 5**< 5**< 5**
Dissolved CO2 [ppm]< 30< 30< 30
Free chlorine [ppm]< 0.1< 0.1< 0.1
TOC-value [ppm]< 2< 2< 2
Hardness [as CaCO3] [ppm]< 300< 300< 300
Iron/manganese [mg/l]< 0.05< 0.05< 0.05
Silica [ppm]< 30< 30< 30
pH range4 up to 104 up to 104 up to 10
* Feed water with high conductivity can reduce the service life of the cartridges and increase the conductivity of type III water. If the conductivity is between 800 and 2000 µS/cm, we recommend using a water softener.** With an SDI/FI between 3 and 5, pre-treatment must be used

OmniaLabRO 20OmniaLabRO 40OmniaLabRO 60
Feedwater connectionR 3/4″R 3/4″R 3/4″
Electrical connection [Volt/Hz]90–240/50–6090–240/50–6090–240/50–60
Connected load [kW]0.10.10.1
Ambient temperature [°C]4 up to 40 [Recommendation: 10 up to 25]4 up to 40 [Recommendation: 10 up to 25]4 up to 40 [Recommendation: 10 up to 25]
Dimensions Tower* [W x H x D mm]511 x 1520 x 575511 x 1520 x 575511 x 1520 x 575
Dimensions Base cabinet tank [W x H x D mm]511 x 800 x 575511 x 800 x 575511 x 800 x 575
Weight [kg]383639
* With OptiFill Dispenser

Article no.System type*Typical applications
18500020OmniaLabRO 20Feedwater for autoclaves and laboratory washers, ultrapure water systems and air humidifiers
18500040OmniaLabRO 40Feedwater for autoclaves and laboratory washers, ultrapure water systems and air humidifiers
18500060OmniaLabRO 60Feedwater for autoclaves and laboratory washers, ultrapure water systems and air humidifiers

Article no.Accessories
19200020Pre-treatment unit 5 µm + hardness stabilization
19200022Pre-treatment unit 5 µm + activated carbon
19200056Disinfection cartridge Omnia
19200057Disinfectant Omnia – 1 Stk./Pkg.
19200058Disinfection kit Omnia (cartridge + 1 pcs. disinfectant)
19200050UV tank disinfection unit Omnia 254
19200054UV flow-through disinfection 254
19200100Docking tank volume 100 liters
16561201External pump station 2 m³/h – 3.5 bar
19200500Volume dosing Omnia
