Pure water for the clinical laboratory.

These water treatment systems reliably supply CLRW/CLSI ultrapure water for analyzers and diagnostic systems in clinical laboratories. Here, the highest purity levels at low operating costs must be combined with high reliability. Therefore, selecting the right water treatment system is the key to seamless and uninterrupted laboratory operation.

OmniaLabDS

The safe one for large amounts of pure water.
For H2O pure CLRW (CLSI) + DIN EN 285 + EN ISO 15883.



If safety is paramount and the quality of the cleaning already determines the quality of the results, then the OmniaLabDS system is the perfect solution.

Even for large pure water volumes up to 60 l/h, the OmniaLabDS guarantees compliance with international water standards in laboratories and medical technology. The combination with regenerative polisher cartridges and an optional emergency supply makes the system predestined for the reliable supply of clinical analyzers. For the supply of steam sterilizers as well as for cleaning and disinfecting devices.

Brochure OmniaLabDS (PDF)
  • OptiFill Dispenser is standard
  • 100 l tank with quality recirculation and pressure outlet
  • Tank volume display in percent
  • Tank volume can be modularly increased
  • Simple, cost-effective filter replacement
  • Leakage sensor is standard
  • Emergency supply (optional)
  • Degassing unit (optional)

OmniaLabDS 20OmniaLabDS 40OmniaLabDS 60
Pure water Typ II + CLRW (CLSI)
DIN EN 285 + ISO EN 15883
Pure water performance at 15 °C [l/h]204060
Conductivity [μS/cm]0.1 up to 1.00.1 up to 1.00.1 up to 1.0
Resistance [MΩ x cm]10 up to 110 up to 110 up to 1
Dispensing performance dispenser [l/min.]up to 2up to 2up to 2
Particles* [1/ml]< 1< 1< 1
Bacteria* [CFU/ml]< 0.01< 0.01< 0.01
Pure water tank pressurized outlet100 l/h – 2 bar100 l/h – 2 bar100 l/h – 2 bar
** With sterile filter capsule 0.2 µm

OmniaLabDS 20OmniaLabDS 40OmniaLabDS 60
Softened or hardness-stabilized water according to DIN 2000
Feedwater pressure [bar]1 up to 61 up to 61 up to 6
Conductivity at 25 °C [µS/cm]< 2000*< 2000*< 2000*
Colloid index SDI< 5**< 5**< 5**
Dissolved C2 [ppm]< 30< 30< 30
Free chlorine [ppm]< 0.1< 0.1< 0.1
TOC-value [ppm]< 2< 2< 2
Hardness [as CaCO3] [ppm]< 300< 300< 300
Iron/manganese [mg/l]< 0.05< 0.05< 0.05
pH range4 up to 104 up to 104 up to 10
* Feed water with high conductivity can reduce the service life of the cartridges and increase the conductivity of type III water. If the conductivity is between 800 and 2000 µS/cm, we recommend using a water softener.** With an SDI/FI between 3 and 5, pre-treatment must be used

OmniaLabDS 20OmniaLabDS 40OmniaLabDS 60
Feedwater connectionR 3/4″R 3/4″R 3/4″
Electrical connection [Volt/Hz]90–240/50–6090–240/50–6090–240/50–60
Connected load [kW]0.10.10.1
Ambient temperature [°C]4 up to 40 [Recommendation: 10 up to 25]4 up to 40 [Recommendation: 10 up to 25]4 up to 40 [Recommendation: 10 up to 25]
Dimensions Tower* [W x H x D mm]511 x 1520 x 575511 x 1520 x 575511 x 1520 x 575
Dimensions Base cabinet tank [W x H x D mm]511 x 800 x 575511 x 800 x 575511 x 800 x 575
Weight (without polisher cartridge) [kg]393840
* with OptiFill Dispenser

Article no.System type*Typical applications
18800020OmniaLabDS 20Feedwater for clinical analyzers, cleaning and disinfection devices, sterilizers
18800040OmniaLabDS 40Feedwater for clinical analyzers, cleaning and disinfection devices, sterilizers
18800060OmniaLabDS 60Feedwater for clinical analyzers, cleaning and disinfection devices, sterilizers
* RO cartridge, stainless steel polishing cartridge, sterile filter capsule 0.2 μm, sterile overflow and sterile vent filter + CO2 absorber included

Article no.Accessories
19200020Pre-treatment unit 5 µm + hardness stabilization
19200022Pre-treatment unit 5 µm + activated carbon
19200056Disinfection cartridge Omnia
19200057Disinfectant Omnia – 1 pcs./Pkg.
19200058Disinfection kit Omnia (cartridge + 1 pcs. disinfectant)
19200050UV tank disinfection unit Omnia 254
19200054UV flow-through disinfection 254
12280050Spare/second cartridge type DS 2800 RV
19200040Emergency supply
19200041Degassing unit
19200100Docking tank volume 100 liters
16561201External pump station 2 m³/h – 3.5 bar
19200500Volume dosing Omnia
